Summary data table of our current fleet. For more information about individual vessels please click on the ship’s name.
Name
Area
Built
IMO
Flag
Cargo Capacity
Jaynee W
UK Europe
1996
9130896
UK
2,516
General Description
Description: 2,750 DWT Double Hull Product Tanker, NAABSA Certified
Year Built: 1996
Flag: UK
Call Sign: MWGT4
IMO: 9130896
Communication: A1 & A2 + Added Equipment
Class: LLOYDS
Trading Area: Limited European Trading
Light Ship: 1,130 Tonnes
Cargo DWT: Summer DWT 2,770 Tonnes
Cargo Equipment
Cargo Pump 1: 1 x Blackmer 600 TpH @ 90 PSI
Cargo Pump 2: 2 x Blackmer 250 TpH @ 90 PSI
Max Loading Rate: 750 M3p/h
Max Discharge Rate: 700 M3p/h x 2 pumps
Tanks Coating: MGO tanks only including 3 wings
Boiler: Wanson 1000B
Ballast Pumps: Desmi S70 250 M3/hr
Ballast Capacity: 1,400 Tonnes
Tank Monitoring: Whessoe
Description: 2,750 DWT Double Hull Product Tanker, NAABSA Certified
Year Built: 1996
Flag: UK
Call Sign: MWGT4
IMO: 9130896
Communication: A1 & A2 + Added Equipment
Class: LLOYDS
Trading Area: Limited European Trading
Light Ship: 1,130 Tonnes
Cargo DWT: Summer DWT 2,770 Tonnes
Cargo Equipment
Cargo Pump 1: 1 x Blackmer 600 TpH @ 90 PSI
Cargo Pump 2: 2 x Blackmer 250 TpH @ 90 PSI
Max Loading Rate: 750 M3p/h
Max Discharge Rate: 700 M3p/h x 2 pumps
Tanks Coating: MGO tanks only including 3 wings
Boiler: Wanson 1000B
Ballast Pumps: Desmi S70 250 M3/hr
Ballast Capacity: 1,400 Tonnes
Tank Monitoring: Whessoe
Cargo Capacity
Capacities given at 95%
H.F.O: 2,080 M3
Gas Oil: 340 M3
Slops: 96 M3
Total cargo capacity: 2,516
Notes:
Dimensions
L.O.A: 75.00 M
L.B.P: 71.27 M
Beam: 12.50 M
Depth: 6.65 M
GT/NT: 1,689/666
Loaded Draft: 4.91 M
Machinery / Speed / Consumption
Main Engines: 2 x Cummins KT-38-M3 @ 684 Kw
Aux Engines: 2 x Cummins 6 CTA 83 G 241 HP
Propeller: 2 x fixed outboard turning with gearbox
Bow Thruster: Cummins Omega 360 KTA 19M 500 HP @ 1,400 RPM
Emergency Harbour Generator:
Crane: Extendable SWL 2T @ 15M max length
Speed: 10 knots @ full load
Bunker Capacity: 75 M3
FW Capacity: 36 M3
Capacities given at 95%
H.F.O: 2,080 M3
Gas Oil: 340 M3
Slops: 96 M3
Total cargo capacity: 2,516
Notes:
Dimensions
L.O.A: 75.00 M
L.B.P: 71.27 M
Beam: 12.50 M
Depth: 6.65 M
GT/NT: 1,689/666
Loaded Draft: 4.91 M
Machinery / Speed / Consumption
Main Engines: 2 x Cummins KT-38-M3 @ 684 Kw
Aux Engines: 2 x Cummins 6 CTA 83 G 241 HP
Propeller: 2 x fixed outboard turning with gearbox
Bow Thruster: Cummins Omega 360 KTA 19M 500 HP @ 1,400 RPM
Emergency Harbour Generator:
Crane: Extendable SWL 2T @ 15M max length
Speed: 10 knots @ full load
Bunker Capacity: 75 M3
FW Capacity: 36 M3
Whitonia
Southampton
2006
9342607
Isle of Man
6,503
General Description
Description: 6,200 DWT Product Tanker
Year Built: 2006
Flag: Isle of Man
Call Sign: MPUN5
IMO: 9342607
Communication: A1 & A2
Class: LLOYDS
Trading Area: English Channel & North European Coastal
Light Ship:
Cargo DWT: Summer DWT 7,500
Cargo Equipment
Cargo Pump 1: Bournemann 1 x Gas Oil 150 M3/hr
Cargo Pump 2: 2 x Fuel Oil 500 M3/hr (each)
Max Loading Rate: 1,000 M3/hr
Max Discharge Rate: 1,000 M3/hr
Tanks Coating: Part Coated
Boiler: Wanson Thermal Fluid
Ballast Pumps: Desmi 2 x 300 M3/hr
Ballast Capacity: 3,042 M3
Tank Monitoring: Tank Radar - ENRAF
Description: 6,200 DWT Product Tanker
Year Built: 2006
Flag: Isle of Man
Call Sign: MPUN5
IMO: 9342607
Communication: A1 & A2
Class: LLOYDS
Trading Area: English Channel & North European Coastal
Light Ship:
Cargo DWT: Summer DWT 7,500
Cargo Equipment
Cargo Pump 1: Bournemann 1 x Gas Oil 150 M3/hr
Cargo Pump 2: 2 x Fuel Oil 500 M3/hr (each)
Max Loading Rate: 1,000 M3/hr
Max Discharge Rate: 1,000 M3/hr
Tanks Coating: Part Coated
Boiler: Wanson Thermal Fluid
Ballast Pumps: Desmi 2 x 300 M3/hr
Ballast Capacity: 3,042 M3
Tank Monitoring: Tank Radar - ENRAF
Cargo Capacity
Capacities given at 95%
H.F.O: 2s & 4s = 3,260 M3 / 2s, 3s & 4s = 4,889 M3
Gas Oil: 1s & 5s = 1,613 M3 / 1s, 3s & 5s = 3,408 M3
Slops:
Total cargo capacity: 6,503
Notes:
Dimensions
L.O.A: 101.08
L.B.P: 95.20
Beam: 18.00
Depth: 8.80
GT/NT: 4,292 / 1,963
Loaded Draft: 6.30
Machinery / Speed / Consumption
Main Engines: 2 x Yanmar 750 kw @ 1,500 rpm
Aux Engines: 2 x CAT 3412 @ 500 kw, 1 x CAT 3406 @ 250 kw
Propeller: Twin Azimuth Thrusters
Bow Thruster: 1 x tunnel thruster @ 450 kw
Emergency Harbour Generator:
Crane: 1 x 16M @ 3T & 1 x 18M @ 1T
Speed: 9 Knots @ 3 Tonnes
Bunker Capacity: 130 M3
FW Capacity: 109 M3
Capacities given at 95%
H.F.O: 2s & 4s = 3,260 M3 / 2s, 3s & 4s = 4,889 M3
Gas Oil: 1s & 5s = 1,613 M3 / 1s, 3s & 5s = 3,408 M3
Slops:
Total cargo capacity: 6,503
Notes:
Dimensions
L.O.A: 101.08
L.B.P: 95.20
Beam: 18.00
Depth: 8.80
GT/NT: 4,292 / 1,963
Loaded Draft: 6.30
Machinery / Speed / Consumption
Main Engines: 2 x Yanmar 750 kw @ 1,500 rpm
Aux Engines: 2 x CAT 3412 @ 500 kw, 1 x CAT 3406 @ 250 kw
Propeller: Twin Azimuth Thrusters
Bow Thruster: 1 x tunnel thruster @ 450 kw
Emergency Harbour Generator:
Crane: 1 x 16M @ 3T & 1 x 18M @ 1T
Speed: 9 Knots @ 3 Tonnes
Bunker Capacity: 130 M3
FW Capacity: 109 M3
Whitchampion
UK Europe
2003
9252280
Isle of Man
4,833
General Description
Description: 4,480 DWT Product Tanker
Year Built: 2003
Flag: Isle of Man
Call Sign: VQPX7
IMO: 9252280
Communication: A1 + A2
Class: LLOYDS
Trading Area: UK & Europe, Can trade Worldwide
Light Ship:
Cargo DWT: Summer DWT 4,200
Cargo Equipment
Cargo Pump 1: Svanehaj Deepwell pumps 200 M3/hr @ 6 bar
Cargo Pump 2: Blackmer lub oil pump 50 M3/hr
Max Loading Rate: 660 M3/hr
Max Discharge Rate: 400 M3/hr
Tanks Coating: Intershield 300 (All tanks fully coated)
Boiler: Wanson Thermopac 1162 Kw @ 3T p/day
Ballast Pumps: 2 x 250 M3/hr @ 2.5 bar
Ballast Capacity: 2,167 M3
Tank Monitoring: Whessoe
Description: 4,480 DWT Product Tanker
Year Built: 2003
Flag: Isle of Man
Call Sign: VQPX7
IMO: 9252280
Communication: A1 + A2
Class: LLOYDS
Trading Area: UK & Europe, Can trade Worldwide
Light Ship:
Cargo DWT: Summer DWT 4,200
Cargo Equipment
Cargo Pump 1: Svanehaj Deepwell pumps 200 M3/hr @ 6 bar
Cargo Pump 2: Blackmer lub oil pump 50 M3/hr
Max Loading Rate: 660 M3/hr
Max Discharge Rate: 400 M3/hr
Tanks Coating: Intershield 300 (All tanks fully coated)
Boiler: Wanson Thermopac 1162 Kw @ 3T p/day
Ballast Pumps: 2 x 250 M3/hr @ 2.5 bar
Ballast Capacity: 2,167 M3
Tank Monitoring: Whessoe
Cargo Capacity
Capacities given at 95%
H.F.O: 3,265 M3
Gas Oil: 1,568 M3
Slops:
Total cargo capacity: 4,833
Notes:
Dimensions
L.O.A: 84.95
L.B.P: 80.80
Beam: 15
Depth: 8.6
GT/NT: 2,965/1,355
Loaded Draft: 6.3
Machinery / Speed / Consumption
Main Engines: 1 x MAK 6M25 1850 Kw @750 rpm
Aux Engines: 2 x Cummins KT19 312 Kw/1 x Cummins 80 Kw
Propeller: 1 x 4 bladed CPP
Bow Thruster: 1 x 600 HP Omega Azimuth 440 Kw
Emergency Harbour Generator:
Crane: 1 x 18M @ 1T
Speed: 10.5 knots @ 90%
Bunker Capacity: 233 M3
FW Capacity: 72 M3
Capacities given at 95%
H.F.O: 3,265 M3
Gas Oil: 1,568 M3
Slops:
Total cargo capacity: 4,833
Notes:
Dimensions
L.O.A: 84.95
L.B.P: 80.80
Beam: 15
Depth: 8.6
GT/NT: 2,965/1,355
Loaded Draft: 6.3
Machinery / Speed / Consumption
Main Engines: 1 x MAK 6M25 1850 Kw @750 rpm
Aux Engines: 2 x Cummins KT19 312 Kw/1 x Cummins 80 Kw
Propeller: 1 x 4 bladed CPP
Bow Thruster: 1 x 600 HP Omega Azimuth 440 Kw
Emergency Harbour Generator:
Crane: 1 x 18M @ 1T
Speed: 10.5 knots @ 90%
Bunker Capacity: 233 M3
FW Capacity: 72 M3
Whitchallenger
UK Europe
2002
9252278
Isle of Man
4,720
General Description
Description: 4,498 DWT Product Tanker, NAABSA Certified
Year Built: 2002
Flag: Isle of Man
Call Sign: VQAU3
IMO: 9252278
Communication: A1 & A2
Class: LLOYDS
Trading Area: Worldwide
Light Ship:
Cargo DWT: Summer DWT 4,200
Cargo Equipment
Cargo Pump 1: 2 x Blackmer 250 M3/hr
Cargo Pump 2: 1 x Blackmer 500 M3/Hr, 1 x Blackmer Lub oil pump 50 M3/Hr
Max Loading Rate: 660 M3/hr per pair of tanks
Max Discharge Rate: 750 M3/hr
Tanks Coating: Epoxy
Boiler: Wanson Thermopac 1,162 kw
Ballast Pumps: 2 x 350 M3/hr @ 2.5 bar
Ballast Capacity: 2,167 M3
Tank Monitoring: Whessoe/MMC
Description: 4,498 DWT Product Tanker, NAABSA Certified
Year Built: 2002
Flag: Isle of Man
Call Sign: VQAU3
IMO: 9252278
Communication: A1 & A2
Class: LLOYDS
Trading Area: Worldwide
Light Ship:
Cargo DWT: Summer DWT 4,200
Cargo Equipment
Cargo Pump 1: 2 x Blackmer 250 M3/hr
Cargo Pump 2: 1 x Blackmer 500 M3/Hr, 1 x Blackmer Lub oil pump 50 M3/Hr
Max Loading Rate: 660 M3/hr per pair of tanks
Max Discharge Rate: 750 M3/hr
Tanks Coating: Epoxy
Boiler: Wanson Thermopac 1,162 kw
Ballast Pumps: 2 x 350 M3/hr @ 2.5 bar
Ballast Capacity: 2,167 M3
Tank Monitoring: Whessoe/MMC
Cargo Capacity
Capacities given at 95%
H.F.O:
Gas Oil: 4,720 M3
Slops: Lubs - 49 M3
Total cargo capacity: 4,720
Notes:
Dimensions
L.O.A: 85
L.B.P: 81
Beam: 15
Depth: 8.6
GT/NT: 2,958/1,355
Loaded Draft: 6.3
Machinery / Speed / Consumption
Main Engines: 1 x MAK 1,850 kw
Aux Engines: 2 x Cummins 312 kw, 1 x Cummins 80 kw hbr set
Propeller: 1 x CPP
Bow Thruster: 1 x Omega Azimuth 440 kw
Emergency Harbour Generator: 1 x Cummins 80 kw
Crane: 2 x 1T x 16M
Speed: 10.5 knots @ 90%
Bunker Capacity: 243 M3
FW Capacity: 82 M2
Capacities given at 95%
H.F.O:
Gas Oil: 4,720 M3
Slops: Lubs - 49 M3
Total cargo capacity: 4,720
Notes:
Dimensions
L.O.A: 85
L.B.P: 81
Beam: 15
Depth: 8.6
GT/NT: 2,958/1,355
Loaded Draft: 6.3
Machinery / Speed / Consumption
Main Engines: 1 x MAK 1,850 kw
Aux Engines: 2 x Cummins 312 kw, 1 x Cummins 80 kw hbr set
Propeller: 1 x CPP
Bow Thruster: 1 x Omega Azimuth 440 kw
Emergency Harbour Generator: 1 x Cummins 80 kw
Crane: 2 x 1T x 16M
Speed: 10.5 knots @ 90%
Bunker Capacity: 243 M3
FW Capacity: 82 M2
Whithaven
Bristol Channel
2005
9334222
Isle of Man
2,931
General Description
Description: 3,000 DWT Product Tanker
Year Built: 2005
Flag: Isle of Man
Call Sign: 2ECT9
IMO: 9334222
Communication: A2
Class: BV
Trading Area: Worldwide
Light Ship:
Cargo DWT: Summer DWT 2,967
Cargo Equipment
Cargo Pump 1: 3 x Tushaco twin screw 350 M3/hr
Cargo Pump 2:
Max Loading Rate: 500 M3/hr
Max Discharge Rate: 350 M3/hr Gas Oil / 700 M3/hr Fuel Oil
Tanks Coating: Marineline Epoxy
Boiler: ZAFA 2 x oil fired steam boilers, 2300-2400 kg/h @ 10-12 bar
Ballast Pumps: 2 x CWZ 150 M3/hr
Ballast Capacity: 1,456 M3
Tank Monitoring: Tank Radar - Krone
Description: 3,000 DWT Product Tanker
Year Built: 2005
Flag: Isle of Man
Call Sign: 2ECT9
IMO: 9334222
Communication: A2
Class: BV
Trading Area: Worldwide
Light Ship:
Cargo DWT: Summer DWT 2,967
Cargo Equipment
Cargo Pump 1: 3 x Tushaco twin screw 350 M3/hr
Cargo Pump 2:
Max Loading Rate: 500 M3/hr
Max Discharge Rate: 350 M3/hr Gas Oil / 700 M3/hr Fuel Oil
Tanks Coating: Marineline Epoxy
Boiler: ZAFA 2 x oil fired steam boilers, 2300-2400 kg/h @ 10-12 bar
Ballast Pumps: 2 x CWZ 150 M3/hr
Ballast Capacity: 1,456 M3
Tank Monitoring: Tank Radar - Krone
Cargo Capacity
Capacities given at 95%
H.F.O: 2,401 M3
Gas Oil: 445 M3
Slops: 86 M3
Total cargo capacity: 2,931
Notes:
Dimensions
L.O.A: 82.98
L.B.P: 79.45
Beam: 12.50
Depth: 6.30
GT/NT: 1,922/835
Loaded Draft: 5.00
Machinery / Speed / Consumption
Main Engines: 2 x CAT 3508 Dita, 746 kw @ 1,800 rpm
Aux Engines: 2 x CAT 3406c, 320 kw @ 1,800 rpm
Propeller: 2 x fixed type, 4 blades, 2,100mm @ 270 rpm
Bow Thruster: 1 x Kalkman Beta 245E 150 kw @ 1,800 rpm
Emergency Harbour Generator: CAT 3406 x, 1 x 250 kw
Crane: 1 x 0.75 Tonne SWL @ 12M
Speed: 11 knots @ 85% on 6.5Mt gas oil on 2 engines, 9.5 knots @ 85% on 3.5Mt gas oil on 1 engine
Bunker Capacity: 85 M3
FW Capacity: 60 M3
Capacities given at 95%
H.F.O: 2,401 M3
Gas Oil: 445 M3
Slops: 86 M3
Total cargo capacity: 2,931
Notes:
Dimensions
L.O.A: 82.98
L.B.P: 79.45
Beam: 12.50
Depth: 6.30
GT/NT: 1,922/835
Loaded Draft: 5.00
Machinery / Speed / Consumption
Main Engines: 2 x CAT 3508 Dita, 746 kw @ 1,800 rpm
Aux Engines: 2 x CAT 3406c, 320 kw @ 1,800 rpm
Propeller: 2 x fixed type, 4 blades, 2,100mm @ 270 rpm
Bow Thruster: 1 x Kalkman Beta 245E 150 kw @ 1,800 rpm
Emergency Harbour Generator: CAT 3406 x, 1 x 250 kw
Crane: 1 x 0.75 Tonne SWL @ 12M
Speed: 11 knots @ 85% on 6.5Mt gas oil on 2 engines, 9.5 knots @ 85% on 3.5Mt gas oil on 1 engine
Bunker Capacity: 85 M3
FW Capacity: 60 M3
Keewhit
UK & Ireland
2003
9286504
UK
2,147
General Description
Description: 2,130 DWT Product Tanker
Year Built: 2003
Flag: UK
Call Sign: MGRK4
IMO: 9286504
Communication: A1 + A2
Class: BV
Trading Area: Mersey & Ireland
Light Ship: 1,131 Tonnes
Cargo DWT: Summer DWT 2,130 Tonnes
Cargo Equipment
Cargo Pump 1: 3 x Electric Centrifugal
Cargo Pump 2:
Max Loading Rate: 450 M3/hr Fuel Oil/300 M3/hr Gas Oil
Max Discharge Rate: 350 M3/hr Fuel Oil/180 M3/hr Gas Oil
Tanks Coating: Epoxy
Boiler: Thermal Oil
Ballast Pumps: 2 x Electric
Ballast Capacity: 963M3
Tank Monitoring: Radar
Description: 2,130 DWT Product Tanker
Year Built: 2003
Flag: UK
Call Sign: MGRK4
IMO: 9286504
Communication: A1 + A2
Class: BV
Trading Area: Mersey & Ireland
Light Ship: 1,131 Tonnes
Cargo DWT: Summer DWT 2,130 Tonnes
Cargo Equipment
Cargo Pump 1: 3 x Electric Centrifugal
Cargo Pump 2:
Max Loading Rate: 450 M3/hr Fuel Oil/300 M3/hr Gas Oil
Max Discharge Rate: 350 M3/hr Fuel Oil/180 M3/hr Gas Oil
Tanks Coating: Epoxy
Boiler: Thermal Oil
Ballast Pumps: 2 x Electric
Ballast Capacity: 963M3
Tank Monitoring: Radar
Cargo Capacity
Capacities given at 95%
H.F.O: 1,776 M3
Gas Oil: 371 M3
Slops:
Total cargo capacity: 2,147
Notes:
Dimensions
L.O.A: 77.18
L.B.P: 69.95
Beam: 11.90
Depth: 5.95
GT/NT: 1,241/616
Loaded Draft: 4.97
Machinery / Speed / Consumption
Main Engines: MAK 8M20 1520Kw
Aux Engines: 2 x MAN 244Kw
Propeller: Berg CPP
Bow Thruster: 1 x 240Kw
Emergency Harbour Generator: 127 KVA
Crane: 1 x 2 Tonne SWL @ 12M
Speed: 11 Knots
Bunker Capacity: MGO 38.9 M3, FO 85.8 M3
FW Capacity: 70 M3
Capacities given at 95%
H.F.O: 1,776 M3
Gas Oil: 371 M3
Slops:
Total cargo capacity: 2,147
Notes:
Dimensions
L.O.A: 77.18
L.B.P: 69.95
Beam: 11.90
Depth: 5.95
GT/NT: 1,241/616
Loaded Draft: 4.97
Machinery / Speed / Consumption
Main Engines: MAK 8M20 1520Kw
Aux Engines: 2 x MAN 244Kw
Propeller: Berg CPP
Bow Thruster: 1 x 240Kw
Emergency Harbour Generator: 127 KVA
Crane: 1 x 2 Tonne SWL @ 12M
Speed: 11 Knots
Bunker Capacity: MGO 38.9 M3, FO 85.8 M3
FW Capacity: 70 M3
Whitstar
UK Europe
2004
9287833
UK
2,858
General Description
Description: 3,100 DWT Product Tanker, 100 A1, ESP, NAABSA Certified, UMS IP, LMC, SCM. ERMA First Ballast Water treatment installed.
Year Built: 2004
Flag: UK
Call Sign: MFTS2
IMO: 9287833
Communication: A1 & A2
Class: LLOYDS
Trading Area: Worldwide
Light Ship: 1,477
Cargo DWT: Summer DWT 3,100
Cargo Equipment
Cargo Pump 1: Deepwwell Marflex 10 x 200 M3/hr
Cargo Pump 2:
Max Loading Rate: 600 M3/hr
Max Discharge Rate: 500 M3/hr
Tanks Coating: Interline Epoxy
Boiler: Aalborg thermal oil via SS Heat exchangers
Ballast Pumps: 2 x 400 M3/hr submerged
Ballast Capacity: 1,576 M3
Tank Monitoring: Tank Radar - Bergan
Description: 3,100 DWT Product Tanker, 100 A1, ESP, NAABSA Certified, UMS IP, LMC, SCM. ERMA First Ballast Water treatment installed.
Year Built: 2004
Flag: UK
Call Sign: MFTS2
IMO: 9287833
Communication: A1 & A2
Class: LLOYDS
Trading Area: Worldwide
Light Ship: 1,477
Cargo DWT: Summer DWT 3,100
Cargo Equipment
Cargo Pump 1: Deepwwell Marflex 10 x 200 M3/hr
Cargo Pump 2:
Max Loading Rate: 600 M3/hr
Max Discharge Rate: 500 M3/hr
Tanks Coating: Interline Epoxy
Boiler: Aalborg thermal oil via SS Heat exchangers
Ballast Pumps: 2 x 400 M3/hr submerged
Ballast Capacity: 1,576 M3
Tank Monitoring: Tank Radar - Bergan
Cargo Capacity
Capacities given at 95%
H.F.O: 2,216 M3
Gas Oil: 642 M2
Slops:
Total cargo capacity: 2,858
Notes:
Dimensions
L.O.A: 75.10
L.B.P: 70.40
Beam: 14.00
Depth: 7.60
GT/NT: 2,159/824
Loaded Draft: 5.76 M
Machinery / Speed / Consumption
Main Engines: MAK 8M25, 2,160 kw @ 750 rpm
Aux Engines: 2 x Daihatsu @ 525 Kva
Propeller: 1 x CPP
Bow Thruster: 1 x Veth 2-K-1000, 220 kw
Emergency Harbour Generator: 80 KVA
Crane: 1 x 0.9 T x 16M
Speed: 10.5 knots @ 90%, 6.5 knots in emergency PTI/PTO mode
Bunker Capacity: 171 M3
FW Capacity: 43 M3
Capacities given at 95%
H.F.O: 2,216 M3
Gas Oil: 642 M2
Slops:
Total cargo capacity: 2,858
Notes:
Dimensions
L.O.A: 75.10
L.B.P: 70.40
Beam: 14.00
Depth: 7.60
GT/NT: 2,159/824
Loaded Draft: 5.76 M
Machinery / Speed / Consumption
Main Engines: MAK 8M25, 2,160 kw @ 750 rpm
Aux Engines: 2 x Daihatsu @ 525 Kva
Propeller: 1 x CPP
Bow Thruster: 1 x Veth 2-K-1000, 220 kw
Emergency Harbour Generator: 80 KVA
Crane: 1 x 0.9 T x 16M
Speed: 10.5 knots @ 90%, 6.5 knots in emergency PTI/PTO mode
Bunker Capacity: 171 M3
FW Capacity: 43 M3
Whitdawn
Gibraltar
2015
9604342
Malta
3,845
General Description
Description: 4,650 DWT Product Tanker
Year Built: 2015
Flag: Malta
Call Sign: 9HA2702
IMO: 9604342
Communication: A3
Class: BV oil tanker ESP Unrestricted Nav, AUT-UMS,MON-SHAFT, Inwater Survey, Clean Ship, DVM-DPS
Trading Area: Unrestricted
Light Ship:
Cargo DWT: Summer DWT 4,650
Cargo Equipment
Cargo Pump 1: 2 x Bournemann 400 M3/h
Cargo Pump 2: 1 x Bournemann 250 M3/hr
Max Loading Rate: 500 M3
Max Discharge Rate: 250 M3 Gas Oil / 600 M3 Fuel Oil
Tanks Coating: Epoxy
Boiler: 2 x S.Man Thermal Fluid
Ballast Pumps: 2 x CWZ 200 M3/h
Ballast Capacity: 2000 M3
Tank Monitoring: Tank Radar Honeywell Cargoboss
Description: 4,650 DWT Product Tanker
Year Built: 2015
Flag: Malta
Call Sign: 9HA2702
IMO: 9604342
Communication: A3
Class: BV oil tanker ESP Unrestricted Nav, AUT-UMS,MON-SHAFT, Inwater Survey, Clean Ship, DVM-DPS
Trading Area: Unrestricted
Light Ship:
Cargo DWT: Summer DWT 4,650
Cargo Equipment
Cargo Pump 1: 2 x Bournemann 400 M3/h
Cargo Pump 2: 1 x Bournemann 250 M3/hr
Max Loading Rate: 500 M3
Max Discharge Rate: 250 M3 Gas Oil / 600 M3 Fuel Oil
Tanks Coating: Epoxy
Boiler: 2 x S.Man Thermal Fluid
Ballast Pumps: 2 x CWZ 200 M3/h
Ballast Capacity: 2000 M3
Tank Monitoring: Tank Radar Honeywell Cargoboss
Cargo Capacity
Capacities given at 95%
H.F.O: Grade 1: 1,345 Tonnes, Grade 2: 1,460 Tonnes
Gas Oil: 1,040 Tonnes
Slops:
Total cargo capacity: 3,845
Notes:
Dimensions
L.O.A: 79.9 M
L.B.P: 75.4 M
Beam: 16.0 M
Depth: 8.20 M
GT/NT: 2,746
Loaded Draft: 1,260
Machinery / Speed / Consumption
Main Engines: 2 x Baudouin, 736 Kw @ 1600 RPM
Aux Engines: 1 x Baudouin, 298 Kw @ 1800 RPM
Propeller: 2 x Fixed type, 4 blades, 2100mm @ 270 RPM
Bow Thruster: 1 x 200 Kw @ 1800 RPM
Emergency Harbour Generator: 1 x Baudouin, 298 Kw @ 1800 RPM
Crane: 3 tonnes SWL @ 16 M
Speed: 10 Knots @ 85%on 6.6 MT Gas Oil
Bunker Capacity: 239 M3
FW Capacity: 100 M3
Capacities given at 95%
H.F.O: Grade 1: 1,345 Tonnes, Grade 2: 1,460 Tonnes
Gas Oil: 1,040 Tonnes
Slops:
Total cargo capacity: 3,845
Notes:
Dimensions
L.O.A: 79.9 M
L.B.P: 75.4 M
Beam: 16.0 M
Depth: 8.20 M
GT/NT: 2,746
Loaded Draft: 1,260
Machinery / Speed / Consumption
Main Engines: 2 x Baudouin, 736 Kw @ 1600 RPM
Aux Engines: 1 x Baudouin, 298 Kw @ 1800 RPM
Propeller: 2 x Fixed type, 4 blades, 2100mm @ 270 RPM
Bow Thruster: 1 x 200 Kw @ 1800 RPM
Emergency Harbour Generator: 1 x Baudouin, 298 Kw @ 1800 RPM
Crane: 3 tonnes SWL @ 16 M
Speed: 10 Knots @ 85%on 6.6 MT Gas Oil
Bunker Capacity: 239 M3
FW Capacity: 100 M3
All details given in good faith but not guaranteed
JOHN H. WHITAKER (TANKERS) LTD
TEl: 00 (44) 01482 595300 | EMAIL: info@whitaker-tankers.co.uk | FAX: 00 (44) 01482 226270
